    63/63.4cbr 4p 63a Schneider Wandao Dual Power Ats Automatic Transfer Switch

    Ask Lasest Price
    Brand Name : Schneider
    Model Number : ATS Automatic Transfer Switch
    Certification : CE
    Price : Negotiable
    Payment Terms : Western Union, T/T
    Supply Ability : 60000 Unit/Units per Month
    Delivery Time : 5- 8 work days
    • Product Details
    • Company Profile

    63/63.4cbr 4p 63a Schneider Wandao Dual Power Ats Automatic Transfer Switch

    63/63.4CBR 4P 63A SCHNEIDER WANDAO DUAL POWER ATS AUTOMATIC TRANSFER SWITCH


    ‌Schneider Wandao dual power ATS automatic transfer switch 63/63.4CBR 4P 63A is a powerful automatic transfer switch suitable for various power switching scenarios to ensure the continuous operation of the equipment. ‌


    Basic parameters and functions

    ‌Model‌63/63.4CBR 4P 63A
    ‌Rated voltage‌400V
    ‌Rated current‌63A
    ‌Number of poles‌4P
    ‌Short circuit connection capacity‌6kA
    ‌Insulation voltage‌50V above 440V and below
    ‌Mechanical life‌5000 times
    ‌Minimum switching time‌800ms
    ‌Warranty period‌18 months

    Application scenarios and advantages
    Schneider Wandao dual power ATS automatic transfer switch is suitable for various power switching scenarios, especially in the fields of industry, energy, infrastructure, data centers, public buildings and residential buildings. Its powerful functions include:

    ‌Automatic conversion function of main and backup power supply‌: Ensure automatic switching to backup power supply when the main power supply fails to ensure that the equipment does not stop.
    ‌Forced to run on main or backup power: Select the main power or backup power as needed.
    ‌Automatic resetting function: Automatically reset to the initial state for easy use.
    ‌Real-time monitoring: Monitor the power status in real time through the controller to ensure stable operation of the system.
    ‌Full protection: With overload long delay, short circuit short delay, ground leakage and other protection functions to ensure safe operation of the equipment.


    Operation method and maintenance
    The operation method is simple. You only need to check the indicator light status and rotate the handle to complete the power switching. Daily maintenance includes regular inspection of the indicator light status, cleaning the switch surface, and ensuring that the operating handle is in the "automatic" state. In addition, the switch complies with IEC and GB standards, and has passed CCC certification and EMC testing to ensure its reliability and safety.

    Class CB Transfer Switch For Automatic Change And Recovery With Overcurrent Release 0
    Class CB Transfer Switch For Automatic Change And Recovery With Overcurrent Release 1
    Wide application
    ● Used in AC220V and AC380V systems
    ● Three operation modes configurable on the site: automatic change and automatic
    recovery, automatic change without automatic recovery, and mutual standby.
    ● Can be easily connected to a smart monitoring system
    High-performance product
    ● High breaking capacity (class CB)
    ● Operation breaking capacity is equal to 100% of ultimate breaking capacity (class
    CB)
    ● Provide high current-limiting capacity and total economic selectivity (class CB)
    ● Provide high short-circuit making capacity and rated short-time withstand capacity
    (class PC)
    Easy connection and installation
    ● No need to derate in both horizontal and vertical installation
    ● No need to derate for lower incoming lines
    Higher reliability
    ● Alarm for wrong neutral connection
    ● Automatic signal cutoff in case of unsuccessful transfer
    Smart communication
    ● RS485 communication interface and Modbus-RTU communication protocol
    ● Provide four remote functions including telecommand, telemetry, telecontrol, and
    telereg
