    CJX2-N AC Reversing Contactor , 3 Phase Reversing Contactor 3P 4P 9A~95A AC-3 AC-1

    Ask Lasest Price
    Brand Name : Chint
    Model Number : CJX2-N
    Certification : CE,CCC,CB etc.
    Price : USD15~USD138
    Payment Terms : T/T, Western Union
    Supply Ability : 1,000pcs/month
    Delivery Time : 5-8 working days or bulk order negotiate
    • Product Details
    • Company Profile

    CJX2-N AC Reversing Contactor , 3 Phase Reversing Contactor 3P 4P 9A~95A AC-3 AC-1

    Chint CJX2-N AC Reversing Contactor 3P, 4P 9A~95A 1810, 2510, 3210, 6511, AC-3 AC-1 Coil Voltage 24V,110V,230V,380V


    characteristic
    • Current range 09~95A;
    • AC, DC control coil is optional (DC coil to 38A);
    • Different types of starters are available: standard motor start contactors, reversible contactors, star-delta starters, autotransformer starters, etc.
    • Optional connection: bolt connection (09~620A), ring terminal connection (09~38A), terminal connection (40~65A), convenient for customer installation;
    • Product Certification: CCC, CE, CCS;


    Advantage
    • Compact installation
    > Contactors to 38A and protection components are only 45mm wide
    > Surge suppressor installation requires no tools and can be inserted directly into the contactor without taking up more space
    > Reversible contactor is only 90mm wide, mechanical interlocking does not take up extra space, installation takes almost no time
    > Starter components provide pre-wired modules for quick and easy assembly
    • Highly integrated
    > to 100A contactor integration 1 normally open / 1 normally closed auxiliary contact
    > DC coil with built-in bidirectional suppression diode
    > Reversible contactor group with built-in bidirectional suppression diode
    • Safe and reliable
    > The main circuit and control circuit of the control and protection components are clearly distinguished
    > Mirrored contact design that meets safety standards, ensuring 10 million reliable actions
    > Protective cover prevents accidental contact of the contactor
    • outstanding quality
    > DC coils have a wide range of control voltages (0.7~1.25Uc)
    > Strong earthquake resistance
    > lower noise
    > Increased terminal strength
    CJX2 40-65A:
    > Permanent torque, reliable installation
    > Compact and space saving
    > Easy to install, saves time
    > Easy to maintain and save costs


    main information
    Product Series
    NC
    product name
    Contactor
    product type
    Reversing contactor
    Product short name
    CJX2-N
    Contactor application area
    Applied to AC loads with a power factor greater than or equal to 0.95
    Squirrel cage motor for switching on and off normal start
    Use category
    AC-1
    AC-3
    Equipment introduction
    Pre-assembled with reversible power supply busbar
    Number of poles
    3P
    Power pole contact composition
    3 NO
    Rated working voltage [Ue]
    Power circuit: <= 690 V AC 25...400 Hz
    Power circuit: <= 300 V DC
    Rated operating current [Ie]
    25 A 60 °C) on <= 440 V AC AC-3 Applicable power circuit
    40 A 60 °C) on <= 440 V AC AC-1 for power supply circuits
    Motor power (kW)
    5.5 kW on 220...230 V AC 50/60 Hz
    11 kW on 380...400 V AC 50/60 Hz
    11 kW on 415...440 V AC 50/60 Hz
    15 kW on 500 V AC 50/60 Hz
    15 kW on 660...690 V AC 50/60 Hz
    Motor power HP (UL / CSA)
    3 hp on 230/240 V AC 50/60 Hz for 1-phase motors
    5 hp on 200/208 V AC 50/60 Hz for 3-phase motors
    2 hp on 115 V AC 50/60 Hz for 1-phase motors
    7.5 hp on 230/240 V AC 50/60 Hz for 3-phase motors
    15 hp on 460/480 V AC 50/60 Hz for 3-phase motors
    20 hp on 575/600 V AC 50/60 Hz for 3-phase motors
    Control loop characteristics
    AC on 50/60 Hz
    Control loop voltage
    220 V AC 50/60 Hz
    Auxiliary contact type
    1 NO + 1 NC
    Rated impulse withstand voltage [Uimp]
    6 kV in accordance with IEC 60947
    Overvoltage category
    III
    Conventional heating current [Ith]
    10 A on <60 °C for signal circuit
    40 A on <60 °C for power supply circuit
    Rated turn-on capability [Irms]
    140 A AC suitable signal circuit in accordance with IEC 60947-5-1
    250 A DC suitable signal loop in accordance with IEC 60947-5-1
    450 A on 440 V applicable power supply circuit in accordance with IEC 60947
    Rated breaking capacity
    450 A on 440 V applicable power supply circuit in accordance with IEC 60947
    Rated short-time withstand current [Icw]
    50 A on <40 °C - 10 minutes for power circuit
    120 A on <40 °C - 1 minute for power circuit
    240 A on <40 °C - 10 s for power supply circuit
    380 A on <40 °C - 1 s for power supply circuit
    100 A - 1 s for signal circuits
    120 A - 500 ms Applicable signal loop
    140 A - 100 ms for signal circuits
    Fuses used with relays
    10 A gG Applicable signal circuit in accordance with IEC 60947-5-1
    63 A gG on ...<= 690 V with type 1 for power supply circuit
    40 A gG on ...<= 690 V with type 2 for power supply circuit
    Average impedance
    2 mΩ - Ith 40 A 50 Hz for power supply circuits
    Rated insulation voltage [Ui]
    690 V complies with IEC 60947-4-1
    600 V CSA certification
    600 V UL certification
    690 V in accordance with IEC 60947-1
    Electrical life
    1.65 kA2.s 25 A AC-3 Ue condition <= 440 V
    1.4 kA2.s 40 A AC-1 Ue condition <= 440 V
    Power consumption per pole
    1.25 W AC-3
    3.2 W AC-1
    Safety cover
    band
    Interlock type
    mechanical
    Installation method
    Rail mounting
    Base plate installation
    Standards compliant
    EN 60947-5-1
    IEC 60947-4-1
    IEC 60947-5-1
    EN 60947-4-1
    certified product
    CCC
    Wiring ability
    Control circuit: Bolt fastening 1 Cable 1...4 mm2 cord without
    Control circuit: Bolt fastening 2 Cable 1...4 mm2 cord without
    Control circuit: Bolt fastening 1 Cable 1...4 mm2 cord
    Control circuit: Bolt fastening 2 Cable 1...2.5 mm2 cord
    Control circuit: Bolt fastening 1 Cable 1...4 mm2 hard wire without
    Control circuit: Bolt fastening 2 Cable 1...4 mm2 hard wire without
    Power circuit: Bolt fastening 1 Cable 2.5...10 mm2 cord without
    Power circuit: Bolt fastening 2 Cable 2.5...10 mm2 cord without
    Power circuit: Bolt tightening 1 Cable 1...10 mm2 cord
    Power circuit: bolt fastening 2 cable 1.5...6 mm2 cord
    Power circuit: bolt fastening 1 cable 1.5...10 mm2 hard wire without
    Power circuit: Bolt fastening 2 Cable 2.5...10 mm2 hard wire without
    Tightening torque
    Control circuit: 1.7 Nm Screwdriver with bolt Ø 6 flat
    Control circuit: 1.7 Nm Screwdriver with No 2 Phillips screw
    Power circuit: 2.5 Nm Screwdriver with bolt Ø 6 flat
    Power circuit: 2.5 Nm Screwdriver with No 2 Phillips screw
    Action time
    12...22 ms closed
    4...19 ms break
    Safety and reliability
    B10d = 1369863 Contactors with nominal load compliance in accordance with EN/ISO 13849-1
    B10d = 20000000 mechanical load contactors comply with EN/ISO 13849-1
    Mechanical life
    15 kA2.s
    Maximum operating frequency
    3600 times / hour on ... <60 °C
    Additional information
    Surge suppression module
    No built-in surge suppression module
    Control voltage limit
    Release: 0.3...0.6 Uc on 50/60 Hz 60 °C)
    Operation: 0.8...1.1 Uc on 50 Hz 60 °C)
    Operation: 0.85...1.1 Uc on ... 60 Hz 60 °C)
    (~50Hz pull-in) power consumption (VA)
    70 VA 60 Hz 0.75 20 °C)
    70 VA 50 Hz 0.75 20 °C)
    (~50Hz hold) power consumption (VA)
    7.5 VA 60 Hz 0.3 20 °C)
    7 VA 50 Hz 0.3 20 °C)
    Heat dissipation
    2...3 W on 50/60 Hz
    Auxiliary contact type
    Type mechanical connection 1 NO + 1 NC in accordance with IEC 60947-5-1
    Type mirrored to the main contact state 1 NC in accordance with IEC 60947-4-1
    Signal loop frequency
    25...400 Hz
    Minimum switching current [Imin]
    5 mA suitable signal loop
    Minimum switching voltage
    17 V for signal circuit
    No overlap time
    1.5 ms between power loss NC and NO contact
    1.5 ms between the NC and NO contacts
    Insulation resistance
    > 10 MΩ for signal circuits
    surroundings
    IP protection level
    IP20 front panel complies with IEC 60529
    Protective measures
    TH conforms to IEC 60068-2-30
    Pollution level
    3
    Operating temperature
    -5...60 °C
    Storage ambient temperature
    -60...80 °C
    Ambient air temperature
    -40...70 °C (allowed under Uc)
    Working elevation
    3000 m without
    Refractory and resistant to abnormal high temperatures
    850 °C in accordance with IEC 60695-2-1
    Flame retardant
    V1 complies with UL 94
    Shock and vibration resistance
    Seismic performance contacts open: 2 gn (5...300 Hz)
    Seismic performance contact closure: 4 gn (5...300 Hz)
    Impact resistance contact closure: 15 gn (11ms)
    Impact resistance contacts open: 8 gn (11ms)
    height
    85 mm
    width
    90 mm
    depth
    92 mm
    product weight
    0.787 kg
