    Double Power 3 Phase AC CB Class 63a 125a Automatic Changeover Switch

    Ask Lasest Price
    Brand Name : Fenigal/OEM
    Model Number : ATS AC CB Class
    Certification : CE,CCC
    Price : Negotiate
    Payment Terms : T/T, Western Union
    Supply Ability : 10,000pcs/month
    Delivery Time : 5-8 working days bulk order negotiate
    • Product Details
    • Company Profile

    Double Power 3 Phase AC CB Class 63a 125a Automatic Changeover Switch

    Double Power 3phase AC CB Class 63a 125a Automatic Transfer Switch changeover switch

    General

    The YAT 400/4P dual-power automatic transfer switch (ATS) is a newly developed miniature household power transfer switch, is mainly used to test whether the main power or reserve power is normal.used in rated voltage below 690V two power supply system. It can make a automatic transfer between the Normal Power and Reserve Power but without manual operation. This switch accords with the following terms of national GB/T14048.11


    When the normal power supply is abnormal, the reserve power supply will start work immediately to ensure continuity, reliability and safety of the power supply. It is specially designed for household rail installation for PZ30 distribution box.


    The ATS is suitable for emergency power supply systems of AC50 or 60Hz and rated voltage 400V. It is featured with firm structure, reliable transfer, easy installation and maintenance, and long life, is widely used in places where frequent power outage is not allowed. Both electric and operation and manual operation are available. The ATS is composed of TES and controller.


    Rated heating current(A)100160250400630100012501600200025003200
    Rated insulation voltage750V1000V
    Rated impulse withstand voltage8KV12KV
    Rated working currentAC-31A100160250400630100012501600200025003200
    AC-35A100160250400630100012501600200025003200
    AC-33A100160250400630100012501600200025003200
    Rated short-time withstand current7KA9KA13KA50KA55KA
    Rated limit short-circuit current100KA70KA100KA120KA80KA
    Control power supply voltageDC 24V 48V 110V , AC 220V
    Conversion time(s)0.511.11.21.252.45
    Quality Double Power 3 Phase AC CB Class 63a 125a Automatic Changeover Switch for sale
