    Class CB Automatic Transfer Switch with Overcurrent Release for AC220V and AC380V Systems

    Class CB Automatic Transfer Switch with Overcurrent Release for AC220V and AC380V Systems


    Class CB
    ATSE with overcurrent release
    Its main contact can be closed and used to break short-circuit current
    WATSN series automatic transfer switch is a class CB automatic transfer switch if it
    adopts a circuit breaker with overcurrent release as the actuator. With selective
    protective function, it can provide short-circuit and overload protection for
    downstream loads and cables. Its making and breaking capacity is significantly
    higher than other components such as contactors and relays.


    Wide application
    ● Used in AC220V and AC380V systems
    ● Three operation modes configurable on the site: automatic change and automatic
    recovery, automatic change without automatic recovery, and mutual standby.
    ● Can be easily connected to a smart monitoring system
    High-performance product
    ● High breaking capacity (class CB)
    ● Operation breaking capacity is equal to 100% of ultimate breaking capacity (class
    CB)
    ● Provide high current-limiting capacity and total economic selectivity (class CB)
    ● Provide high short-circuit making capacity and rated short-time withstand capacity
    (class PC)
    Easy connection and installation
    ● No need to derate in both horizontal and vertical installation
    ● No need to derate for lower incoming lines
    Higher reliability
    ● Alarm for wrong neutral connection
    ● Automatic signal cutoff in case of unsuccessful transfer
    Smart communication
    ● RS485 communication interface and Modbus-RTU communication protocol
    ● Provide four remote functions including telecommand, telemetry, telecontrol, and
    telereg
    Notes:
    Controller types include: A - Terminal type; B - Basic Type; D- Smart type
    Frame current levels: 63, 100, 160, 250, 400, 630, 800, 1000, 1250, 1600
    Rated current: Depending on different frame levels, the release is selected by the user (by making reference to NSX/NS circuit breaker sample)
    Selectable number of poles: 2 (only for iC65 series), 3, 4 (all series)
    Electric device Class: CB - with short-circuit and overload protection
    Operation modes: R - Automatic change and automatic recovery; S - Automatic change without automatic recovery; I - Mutual standby
    Additional functions: X- Fire protection linkage; F- Feedback signal; I - Current monitoring module (only available for Type D controller)
    Release – class CB. Release with different protection range can be selected based on user needs.
    *: Two installation methods can be provided: Device-mounted and panel-mounted.
    Please add a note if panel installation is required. iC65 products do not support
    panel-mounted controllers.
    **: F- Feedback signal function (including position feedback and alarm feedback, please add explanatory text if necessary).800-1600A series products include a group of position feedback and a group of alarm feedback as standard. For 63A and lower current products, only a group of position feedback is available.
